| Model | KH60-A/150L | KH60-A/200L | KF60-A/250L | KF60-A/300L | KF80-A/150L | KF80-A/200L | KF80-A/250L | KF80-A/300L | ||
| Heating capacity | Kw | 1.8 | 1.8 | 1.8 | 1.8 | 2.8 | 2.8 | 2.8 | 2.8 | |
| COP | W/W | 3.6 | 3.6 | 3.6 | 3.6 | 3.5 | 3.5 | 3.5 | 3.5 | |
| Water tank volume | L | 150 | 200 | 250 | 300 | 150 | 200 | 250 | 300 | |
| Rated outlet water temp | ℃ | 55 | ||||||||
| Max outlet water temp | ℃ | 60 | ||||||||
| Rated heated water output | L/H | 39 | 39 | 39 | 39 | 60 | 60 | 60 | 60 | |
| Rated power input | W | 500 | 500 | 500 | 500 | 800 | 800 | 800 | 800 | |
| Rated current | A | 2.4 | 2.4 | 2.4 | 2.4 | 3.8 | 3.8 | 3.8 | 3.8 | |
| Electric heater power | W | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | |
| Electric heater current | A | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | |
| Power supply | V/Hz | 220~240/50 | ||||||||
| Compressor type | Rotary | |||||||||
| Number of compressor | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Heat exchanger type | External coil | |||||||||
| Throttling device | Electrical Expansion Valve | |||||||||
| Fan type | High Efficiency and Low Noise Centrifugal Fan | |||||||||
| Fan discharging | Top with 5m Exhuast Pipe | |||||||||
| Fan quanlity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Fan input | W | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | |
| Fan speed | RPM | 920 | 920 | 920 | 920 | 920 | 920 | 920 | 920 | |
| Ambient temperature | ℃ | (0~43) | ||||||||
| Refrigerant | R134A / R410A | |||||||||
| Noise in 1 meter distance | dB(A) | 43 | 43 | 43 | 43 | 43 | 43 | 43 | 43 | |
| Water pipe connection size | inch | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | |
| Cabinet | Galvanized Powder Coated Steel | |||||||||
| Low pressure protection system | Yes | |||||||||
| High pressure protection system | Yes | |||||||||
| Automatic defrosting system | Yes | |||||||||
| Product Dimension | mm | φ560*1500 | φ560*1700 | φ560*1970 | φ650*1800 | φ560*1800 | φ560*1700 | φ560*1970 | φ650*1800 | |
| Product Net weight | Kg | 78 | 84 | 90 | 100 | 81 | 87 | 93 | 103 | |
| Model | KH60-A/150L | KH60-A/200L | KF60-A/250L | KF60-A/300L | KF80-A/150L | KF80-A/200L | KF80-A/250L | KF80-A/300L | ||
| Heating capacity | Kw | 1.8 | 1.8 | 1.8 | 1.8 | 2.8 | 2.8 | 2.8 | 2.8 | |
| COP | W/W | 3.6 | 3.6 | 3.6 | 3.6 | 3.5 | 3.5 | 3.5 | 3.5 | |
| Water tank volume | L | 150 | 200 | 250 | 300 | 150 | 200 | 250 | 300 | |
| Rated outlet water temp | ℃ | 55 | ||||||||
| Max outlet water temp | ℃ | 60 | ||||||||
| Rated heated water output | L/H | 39 | 39 | 39 | 39 | 60 | 60 | 60 | 60 | |
| Rated power input | W | 500 | 500 | 500 | 500 | 800 | 800 | 800 | 800 | |
| Rated current | A | 2.4 | 2.4 | 2.4 | 2.4 | 3.8 | 3.8 | 3.8 | 3.8 | |
| Electric heater power | W | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | |
| Electric heater current | A | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | |
| Power supply | V/Hz | 220~240/50 | ||||||||
| Compressor type | Rotary | |||||||||
| Number of compressor | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Heat exchanger type | External coil | |||||||||
| Throttling device | Electrical Expansion Valve | |||||||||
| Fan type | High Efficiency and Low Noise Centrifugal Fan | |||||||||
| Fan discharging | Top with 5m Exhuast Pipe | |||||||||
| Fan quanlity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Fan input | W | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | |
| Fan speed | RPM | 920 | 920 | 920 | 920 | 920 | 920 | 920 | 920 | |
| Ambient temperature | ℃ | (0~43) | ||||||||
| Refrigerant | R134A / R410A | |||||||||
| Noise in 1 meter distance | dB(A) | 43 | 43 | 43 | 43 | 43 | 43 | 43 | 43 | |
| Water pipe connection size | inch | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | |
| Cabinet | Galvanized Powder Coated Steel | |||||||||
| Low pressure protection system | Yes | |||||||||
| High pressure protection system | Yes | |||||||||
| Automatic defrosting system | Yes | |||||||||
| Product Dimension | mm | φ560*1500 | φ560*1700 | φ560*1970 | φ650*1800 | φ560*1800 | φ560*1700 | φ560*1970 | φ650*1800 | |
| Product Net weight | Kg | 78 | 84 | 90 | 100 | 81 | 87 | 93 | 103 | |
